Cold Extrusion Machine JYJ32/40

Cold Extrusion Machine JYJ-32/40

Cold Extrusion Machine Processing range:16mm-32mm Main motor power:4.5KW/5.5KW Power supply:3P 380Volt 50HZ/60HZ A hydraulic device that joins steel bars by radially squeezing a steel sleeve onto their ends. The deformed sleeve interlocks with the bar ribs, forming a strong connection.

Inquire

Cold Extrusion Machine JYJ-32/40

Product Characteristic

Part Name	Cold Extrusion Machine	Part Name	Cold Extrusion Machine
Machine Type	JYJ-32	Main Motor Power	JYJ-40
size(mm)	Oil Pump size:500450600mm Clamp Size:300200200mm	size(mm)	Oil Pump size:550530752mm Clamp Size:380240240mm
Weight (kg)	Oil Pump Weight:65kg/set Clamp Weight:30kg/set	Weight (kg)	Oil Pump Weight:79kg/set Clamp Weight:39kg/set
Hydraulic Oil	32#	Hydraulic Oil	11KW/380V/50Hz
Main motor power	4.5KW	Main motor power	5.5KW
Power supply:	3P 380Volt 50HZ/60HZ	Power supply:	3P 380Volt 50HZ/60HZ

Introduction:

A hydraulic device that joins steel bars by radially squeezing a steel sleeve onto their ends. The deformed sleeve interlocks with the bar ribs, forming a strong connection.

This high-strength, efficient, and clean method replaces welding and threading. Ideal for critical structures like skyscrapers, nuclear plants, and bridges.

Product Advantage:

High Strength: Joint strength exceeds 110% of base steel bar, ensuring reliable performance.
Safe & Versatile: No open flames or weather constraints, ideal for hazardous environments.
Eco-Friendly: No heat source, fumes, or slag; low noise.
Easy to Operate: Minimal training required, low labor intensity.
Wide Compatibility: Connects bars of different alignments and diameters, suitable for various steel grades.
Simple QC: Easy visual and caliper-based inspection of indentations and expansion
